DNV 2.7-1 Standard 20ft Offshore Tank Container
Key Feature for 20ft Offshore Tank Container
Complies with DNV2.7-1:2006 Standard.
Complies with EN12079-2006 Standard.
Materials: Frame: SPA-H, Tank Shell: 316L
Design Temperature: Frame: -20°C, Tank: -40 °C
DNV2.7-1 Certificate: Issured by DNV, LR
Design Standard: DNV2.7-1,EN12079,IMDG, ASME VIII Div 1, ADR/RID
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
| Specifications: | |||
| Dimensions (L x W x H) | External | 2.150 x 1.850 x 2.134 | M |
| 85’’ x 73’’ x 84’’ | FT-IN | ||
| Max. Capacity (Nominal) | 2700 | L | |
| 713 | Gallon(US) | ||
| Max. Filling capacity | 2565 | L | |
| 678 | Gallon(US) | ||
| Max. Gross Mass | 8000 | KGS | |
| Tare Mass (Nominal) | 1920 | KGS | |
| Max. Payload | 6080 | KGS | |
| Pressure | Design pressure | 0.267 | Mpa |
| Test pressure | 0.4 | Mpa | |
| Design Temperature | Frame | -20℃ | |
| Tank | -40℃ | ||
| Stacking | in warehouse | 2 high | |
| in transport | 1 high | ||
| Specifications: | |||
| Dimensions (L x W x H) | External | 2.150 x 1.850 x 2.134 | M |
| 85’’ x 73’’ x 84’’ | FT-IN | ||
| Max. Capacity (Nominal) | 2700 | L | |
| 713 | Gallon(US) | ||
| Max. Filling capacity | 2565 | L | |
| 678 | Gallon(US) | ||
| Max. Gross Mass | 8000 | KGS | |
| Tare Mass (Nominal) | 1920 | KGS | |
| Max. Payload | 6080 | KGS | |
| Pressure | Design pressure | 0.267 | Mpa |
| Test pressure | 0.4 | Mpa | |
| Design Temperature | Frame | -20℃ | |
| Tank | -40℃ | ||
| Stacking | in warehouse | 2 high | |
| in transport | 1 high | ||
